PMC-1000S Gigabit Ethernet 10/100/1000BaseTx to SFP slot fiber media converter with PoE+ 30W injector

(No reviews yet) Write a Review
SKU:
PMC-1000S
UPC:
811704015302
Availability:
Ships same day for orders placed before 3:30PM PST

Quantity Discount

Product price $149.00
Buy 10 or above $141.55
MSRP: $229.00
$149.00
— You save $80.00

Description

Note: This Gigabit media converter does NOT include the SFP transceiver module.

Product description
This Gigabit converter is a PoE PSE injector equipment. It provides power over the Ethernet copper UTP cable to power up end devices like VoIP phones, WiFi APs or IP Surveillance cameras. It is compatible with the PoE 802.3af and 802.3at standards and delivers maximum power of 30W over the UTP RJ45 port, suitable even for the most power consuming wireless equipment.

The PMC-1000S Gigabit Ethernet is an extremely versatile optical fiber media converter for 10/100/1000Base-T copper to Gigabit SFP slot. Any 1000Base-SX/LX/LHX/ZX or WDM/CWDM SFP transceiver can be installed in the media converter. Unit has a separate AC power supply. PMC-1000S Gigabit fiber media converter is equipped with a PoE+ injector compatible with 802.3af/at Power over Ethernet standards that allows connection of any PoE device such as IP phones or IP surveillance cameras, eliminating the need of remote powering or additional cabling.


Technical specifications

Interfaces: RJ45 copper IEEE 802.3 10Base-T, 802.3u 100Base-TX, 802.3ab 1000Base-T and SFP slot for 802.3z 1000Base- SX/LX/ZX standards
Connectors: RJ-45 copper 10/100/1000 Mbps and SFP slot 1000Mbps
UTP port: MDI/MDI-X, auto-negotiation, Full/Half Duplex, max. packet 1632 bytes, provides PoE 802.3af/802.3at standards with 30W max power budget for externally powered PoE devices
Optical slot: Small Form Pluggable - supports Auto and Forced mode operation
Front LEDs: PWR, Fiber duplex, Fiber Link, TP Link, TP Duplex, TP Speed
Power: Embedded 90-260V AC power, 3 pin cord, US type main plug
Temperature: 0 50°C (Operating); -10 70°C (Storage)
Humidity: 20 80% non condensing (Operating); 0 90% (Storage)
Consumption: less than 35W (at full PoE+ consumption)
Dimensions(WxDxH): 108mm x 74mm x 23mm with separate AC adapter
Weight: 480g (80g for converter only)
Compliance: CE, FCC Class A
MTBF: 75,000 hours


Additional information on PMC-1000S converter: PDF Datasheet; PDF Installation Manual.

Note: To have a complete Gigabit media converter, you must also order an SFP transceiver module together with the PMC-1000S converter. Please visit the SFP transceiver module page or contact our sales department by e-mail or telephone.

View AllClose

Warranty Information

2 years
View AllClose

Additional Information

Interface Type:
Fast Ethernet
Interface Type:
Gigabit Ethernet
Management:
un-managed
Transceiver Format:
SFP
Power Type:
AC 90-240V embedded PSU
Connectors:
RJ45 (Ethernet)
Connectors:
SFP slot
PoE Output:
30 Watts/port
Features:
LFP Link Fault Pass through
View AllClose
